Description
The automatic frequency conversion water supply equipment is a new generation of products with advanced foreign technology combined with fire, life and production water. It adopts microcomputer programmable control technology, according to various conditions of water supply pipe network and water source, by micro Computer control regulates all kinds of complicated work and realizes intelligent water supply.
System function and description
1. Pressure adjustment: freely adjustable within the performance curve of the pump
2. Automatic shutdown: the system can automatically stop after 20 seconds without water, and the pressure will not deviate from the set value by 1% after shutdown.
3. Normal water consumption: When the system pressure is lower than 85% of the set pressure, the pump starts up automatically and maintains constant pressure water supply.
4. Water shortage protection: When the pump’s full-speed running pressure still cannot reach 65% of the set value, the pump will automatically stop running after 30 seconds.
5. Other protection: overload, over current, high and low voltage protection, etc.
