Description
PUMP
Single Phase | Heavy Duty Continuous Work |
Pump body | Cast Iron |
Impeller | Brass/Stainless Steel/Techno-polymer(P.P.O) |
Mechanical Seal | SIC/Ceramic/Graphite |
MOTOR
Motor Housing | Aluminum Alloy |
Shaft | Carbon steel/stainless steel |
Insulation | ClassB/Class F |
Protection | IP44/IP54 |
Cooling | External Ventilation |
Operation Conditions
Liquid temperature up to 60℃
Ambient temperature up to 40℃
Total suction lift up to 9m
Continuous duty
