GP Electric Self-Priming Water Pump

Home GP Electric Self-Priming Water Pump

ＧＰ　GP SERIES SELF-PRIMING PERIPHERAL PUMPS Pump >> Pump Body: cast iron & support under special anti-rust treatment >> Impeller: brass impeller >> Mechnical Seal: carbon / ceramic / Stainless Steel Motor >> Bulit-in thermal protector for single phase motor >> Motor with copper winding >> Motor Housing: Steel-plate, Aluminum alloy >> AISI 304 shaft or 45# carbon steel Application GP series automatic self-priming water pumps are suitable for pumping clean water. Consisted of a water pump, a tank and a pressure switch, this series is relatively simple construction, not expensive but reliable and safe. TECHINICAL DATA AT 220-240V/50HZ MODEL POWER MAX.FLOW MAX.HEAD MAX.SUCT INLET/OUTLET GW PACKING DIMENSION(MM) kW HP (l/min) (M) (M) (inch) (kgs) GP-125A 0.125 1/6 30 30 9 1" x 1" 6.6 260*200*240 GP-250A 0.37 1/2 35 35 9 1" x 1" 7 260*200*240
GP SERIES SELF-PRIMING PERIPHERAL PUMPS Pump >> Pump Body: cast iron & support under special anti-rust treatment >> Impeller: brass impeller >> Mechnical Seal: carbon / ceramic / Stainless Steel Motor >> Bulit-in thermal protector for single phase motor >> Motor with copper winding >> Motor Housing: Steel-plate, Aluminum alloy >> AISI 304 shaft or 45# carbon steel Application GP series automatic self-priming water pumps are suitable for pumping clean water. Consisted of a water pump, a tank and a pressure switch, this series is relatively simple construction, not expensive but reliable and safe. TECHINICAL DATA AT 220-240V/50HZ MODEL POWER MAX.FLOW MAX.HEAD MAX.SUCT INLET/OUTLET GW PACKING DIMENSION(MM) kW HP (l/min) (M) (M) (inch) (kgs) GP-125A 0.125 1/6 30 30 9 1" x 1" 6.6 260*200*240 GP-250A 0.37 1/2 35 35 9 1" x 1" 7 260*200*240
GP SERIES SELF-PRIMING PERIPHERAL PUMPS Pump >> Pump Body: cast iron & support under special anti-rust treatment >> Impeller: brass impeller >> Mechnical Seal: carbon / ceramic / Stainless Steel Motor >> Bulit-in thermal protector for single phase motor >> Motor with copper winding >> Motor Housing: Steel-plate, Aluminum alloy >> AISI 304 shaft or 45# carbon steel Application GP series automatic self-priming water pumps are suitable for pumping clean water. Consisted of a water pump, a tank and a pressure switch, this series is relatively simple construction, not expensive but reliable and safe. TECHINICAL DATA AT 220-240V/50HZ MODEL POWER MAX.FLOW MAX.HEAD MAX.SUCT INLET/OUTLET GW PACKING DIMENSION(MM) kW HP (l/min) (M) (M) (inch) (kgs) GP-125A 0.125 1/6 30 30 9 1" x 1" 6.6 260*200*240 GP-250A 0.37 1/2 35 35 9 1" x 1" 7 260*200*240

GP series self-priming peripheral electric pumps are suitable to tansfer clean water.It is consisted of a water pump,a tank,a pressure switch and relevant accessory.It is mainly used in domestic water supply and pressure rise from well or pond.

Operation ConditionsLiquid temperature up to 60℃

Ambient temperature up to 40℃

Total suction lift up to 9m

Continuous duty

PUMP
Single PhaseHeavy Duty Continuous Work
Pump bodyCast Iron
ImpellerBrass/Stainless Steel
Mechanical SealSIC/Ceramic/Graphite

MOTOR

Motor HousingAluminum Alloy/Cast Iron
ShaftCarbon steel/stainless steel
InsulationClassB/Class F
Protection IP44/IP54
CoolingExternal Ventilation

Add to wishlist
Category: Tags: , , , ,

Description

GP SERIES SELF-PRIMING PERIPHERAL PUMPS
Pump
>> Pump Body: cast iron & support under special anti-rust treatment
>> Impeller: brass impeller
>> Mechnical Seal: carbon / ceramic / Stainless Steel

Motor
>> Bulit-in thermal protector for single phase motor
>> Motor with copper winding
>> Motor Housing: Steel-plate, Aluminum alloy
>> AISI 304 shaft or 45# carbon steel

Application

GP series automatic self-priming water pumps are suitable for pumping clean water. Consisted of a water pump, a tank and a pressure switch, this series is relatively simple construction, not expensive but reliable and safe.

TECHINICAL DATA AT 220-240V/50HZ

MODELPOWERMAX.FLOWMAX.HEADMAX.SUCTINLET/OUTLETGWPACKING DIMENSION(MM)
kWHP(l/min)(M)(M)(inch)(kgs)
GP-125A0.1251/6353591″ x 1″6.6260*200*240
GP-250A0.371/2403591″ x 1″7260*200*240
