Vibration masking pump is designed for clean water lifting from boreholes with a diameter over 105mm and depth up to 70 meters, water wells and any reservoirs, it can be used for watering vegetable gardens, as well as for domestic water supply.Elestar Pumps are EVM baby submerged Russian pump convenient easy install for home use suppliers & manufacturing company. Now You can wholesale direct from Factory.
The pump is designed for clear water lifting from boreholes, water wells and any reservoirs, it can be used for watering vegetable gardens, as well as for domestic water supply. It is one of the best selling pump items for East European market, especially for Russia.
PERFORMANCE RANGE
Flow rate up to 40/min
Head up to 80m
OPERATION CONDITIONS
Liquid temperature up to +35 C
Ambient temperature up to +40 C
Max Working pressure 8 bar
Continuous duty
ELECTRIC MOTOR
Two pole induction motor, 50HZ
Single phase 220V-240V
Insulation dass F
Protection IP68
· Max. medium temperature+40°C
· Max. ambient temperature+40°C
· PH level from 6.5-8.5
· Maximum sand content is 01%.Passage of suspended solids up to 0.2mm.
· Voltage fluctuation range:0.9-1.1 times of the rated value lmmersion depth from 0.5m-5m
· Submersion depth:5m
Motor information
· Two-pole induction motor
· Single phase/three phase,50/60Hz(on demand)
· Insulation class:B
