Description
PUMP
| Single Phase | Heavy Duty Continuous Work |
| Pump body | Cast iron |
| Impeller | Brass/Stainless Steel/Techno-polymer(P.P.O) |
| Mechanical Seal | SIC/Ceramic/Graphite |
MOTOR
| Motor Housing | Aluminum Alloy |
| Shaft | Carbon steel/stainless steel |
| Insulation | ClassB/Class F |
| Protection | IP44/IP54 |
| Cooling | External Ventilation |
| APPLICATIONS – Self priming water pumps for deep suctions up to 25m to be used in case of important water level gaps. – Suitable to drain water from wells and in domestic fittings by small and medium sized tanks. – Before installing the pump verify that all pipes (iron, plastic or rubber) are clean inside so to avoid any obstruction to the ejector nozzle. At the foot of the ejector must be installed a foot valve or a check valve. Installed the pump, fill completely both pipes and pump body with clean water. To preserve an efficient priming it is necessary a certain pression in the circuit, therefore it is recommended to install a membrane tank at the delivery of the pump. | |
| OPERATING LIMITS -Total suction lift up to 9 mt. with foot valve -Max. operating pressure: 8 bar. -Max. ambient temperature: +40ºC -Lliquid temperature up to: +60ºC -Max. altitude: +1000 m. | DESIGN FEATURES -Pump body:cast iron -Impeller: Brass -Ejector union:PPO -Internal thermal protector -Motor shaft: AISI1045 -Mechanical seal: NBR/Graphite/Ceramic |
| MOTOR -Single phase power supply with capacitor permanently activated -Insulation class: B -Protection: IP44 -Speed of rotation: 2850rpm -Continuous duty: S1 | SPECIAL FEATURES ON REQUEST -Stainless steel welding shaft. -PPO or SUS304 impeller -FPM/EPDM/SIC/WC mechanical seal -Other voltage and frequency -Three phase power. -Electrophoresis anti-rust treatment |
