Description
Centrifugal pumps are widely used for transporting fluids by converting rotational kinetic energy to the hydrodynamic energy of fluid flow. These pumps are essential in various applications due to their efficiency and ability to handle different types of fluids.Centrifugal pumps work by converting mechanical energy from a motor into kinetic energy in the fluid being pumped.
| Single Phase | Heavy Duty Continuous Work |
| Pump body | Cast Iron |
| Impeller | Brass/Techno-polymer |
| Mechanical Seal | SIC/Ceramic/Graphite |
MOTOR
| Motor Housing | Aluminum Alloy |
| Shaft | Carbon steel/stainless steel |
| Insulation | ClassB/Class F |
| Protection | IP44/IP54 |
| Cooling | External Ventilation |
CPM series are single stage centrifugal pumps,can be used to transfer clean water or other similar water in physical and chemical properties .It is suitable for industrial use and urban water supply,pressure boosting for high buildings and fire system,garden irrigation,long-distance water transfer,heating ventilation and air controlling,circulation and pressure boosting for cold and hot water,and supporting equipment etc.
Operation Conditions
Liquid temperature up to 60℃
Ambient temperature up to 40℃
Total suction lift up to 9m
Continuous duty
